— Quotation QU-3447 —
Layer Project Management has asked Sterling Temple to quote for a measured building survey of BACB, 8–10 Mansion House Place, London EC4N 8BJ, to validate the existing basement and ground floor plans. The survey will be undertaken by high-accuracy 3D laser scanning in accordance with RICS guidelines.
Drawings will be updated on the existing DWG base supplied (22-7223-01-00_AB) and issued in DWG (CAD) and PDF formats, together with a schedule of discrepancies identified between the existing drawings and the surveyed layout.
— 01 —
Full dimensional survey of the basement and ground level floor plans, validated against the existing DWG base and issued in DWG (CAD) and PDF formats.
— 02 —
Measurement of the ground floor store room and its incorporation into the ground floor plan.
— 03 —
Measurement of the lightwell running along the front of the building and its incorporation into the plans.
— 04 —
A schedule of discrepancies identified between the existing drawings and the surveyed layout, issued as a marked-up PDF.
DWG
Updated basement and ground floor plans on the supplied DWG base
Floor plans issued as PDF for review and distribution
Schedule of discrepancies, marked up against the record drawings
| Description | Unit | Unit price |
|---|---|---|
| Measured survey and validation of the basement and ground level floor plans — full dimensional survey of all basement rooms and corridors with clear room dimensions, and floor-to-ceiling heights recorded and annotated for all rooms and circulation areas; issued in DWG (CAD) and PDF formats. | item | £1,195.00 |
| Ground floor store room — measurement and incorporation into the ground floor plan. | item | £90.00 |
| Lightwell running along the front of the building — measurement and incorporation into the plans. | item | £90.00 |
| Schedule of discrepancies identified between the existing drawings and the surveyed layout, issued as a marked-up PDF. | item | £110.00 |
| Subtotal | £1,485.00 | |
| VAT at 20% | £297.00 | |
| Total | £1,782.00 | |
Measured survey and validation of the basement and ground level floor plans — full dimensional survey of all basement rooms and corridors with clear room dimensions, and floor-to-ceiling heights recorded and annotated for all rooms and circulation areas; issued in DWG (CAD) and PDF formats.
Ground floor store room — measurement and incorporation into the ground floor plan.
Lightwell running along the front of the building — measurement and incorporation into the plans.
Schedule of discrepancies identified between the existing drawings and the surveyed layout, issued as a marked-up PDF.
— Options —
Figures are in GBP. VAT is charged at the prevailing rate. This quotation is valid until 17 September 2026. VAT number 198505077.
Working days from instruction, subject to access.
Stage 01
Within 5 working days
Site attendance
From instruction, subject to BACB security clearance and access arrangements
Stage 02
Approx. 1 day
On site
Single escorted visit during normal business hours
Stage 03
5 working days
Updated drawings issued
From the site visit
Sterling Temple surveys using high-accuracy 3D laser scanning, capturing a fully registered point cloud of every accessible area in a single mobilisation. The point cloud is processed and cleaned, then drawn up in BricsCAD and AutoCAD directly onto the existing DWG base so that the updated plans remain coordinated with the record information. All work is carried out in accordance with RICS guidelines and dimensions are stated in metres.
